Chongqing Hongli Motorcycle Manufacture Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | OEM |
| Model Number : | HL-YMH |
| Price : | $480.00 - $850.00/units |
Engine Type: | Single cylinder,water-cooled, DOHC ,Four-stroke ,4
valves,Counterbalance shaft | Front Suspension: | 940±3mm,290mm,φ48mm,Adjustable |
Displacement (ml): | 250.2 | Rear Suspension: | 408±2mm,80mm,φ12mm,Adjustable |
Bore X Stroke (mm): | 70x65 | Chassis structure : | Material:Q235/Material:6061 |
Compression Ratio: | 11:1 | Rear Swing arm: | Alloy Material:6061 |
Max. Power (kw/r/min) | 18/9000±500 | Handlbar: | forgings and extrusions ,φ28↘φ22 |
Max. Torque (N.m/r/min): | 21/8500±500 | Front Brake: | Hydraulic twin piston Disc Brake |
Max. Speed (Km/h): | ≥110 | Rear Brake: | Hydraulic single piston Disc Brake |
Min. Fuel Consumption (g/kW.h) | ≤354 | Front Tire: | 80/100-21 (offroad tire); 110/70-17 (road tire) |
Lubrication: | Pressure ,splash | Rear Tire: | 110/100-18 (offroad tire); 140/70-17 (road tire) |
Clutch Type: | Manual, Multiplate wet clutch | Muffler: | Stainless steel exhaust pipe. Alloy muffler |
Ignition: | CDI | Steering Head Angle: | Adjustable Steering system |
Starting System: | Electric | Battery: | 12V6.5Ah(dry battery) |
Transmission System: | Chain drive with 6 gears | L X W X H (mm): | 2184×832×1259 |
|
|
